Turbosound - iQ10 2500 Watt 2 Way 10" Powered Loudspeaker
TURBOSOUND-IQ10
The 2,500-Watt iQ10 is a powered two-way loudspeaker ideally suited for a wide range of portable and fixed installation, music and speech sound reinforcement applications. The driver complement includes an 10" low frequency driver with a low mass voice coil for improved transient response, and a high temperature 1" compression driver with copper-clad aluminium voice coil for extended high frequency reproduction.
FEATURES
2 way full range loudspeaker for portable PA and installation applications
2,500 Watt power featuring KLARK TEKNIK Class-D technology
KLARK TEKNIK Digital Signal Processing for total system control
Speaker modelling includes accurate models of industry standard speakers
SCC (Spatial Contour Control) compensates frequency response in relation to physical speaker placement
ULTRANET digital audio networking connects to mixers and other sources
10" low frequency driver with low mass voice coil for improved transient response
High temperature 1" compression driver with copper-clad aluminium voice coil for extended high frequency reproduction
Fully featured user interface with LCD display for ease of navigation
PC remote control software downloadable at turbosound.com
Lightweight fibre glass reinforced composite enclosure
Rugged powder coated perforated steel mesh grille
Dual angle pole mount for accurate audience coverage
Multiple internal rigging points for installation applications
Mains input and link output on Neutrik powerCON connectors
SPECIFICATIONS
Frequency response | 55 Hz – 18 kHz ±3 dB |
Nominal dispersion | 90° H x 60° V @ -6 dB points |
Maximum SPL | 129 dB peak |
Crossover type | Active |
Transducers | 1 x 10" (256 mm) LF driver |
Limiter | Independent HF, LF, peak and rms |
Amplifier
Maximum output power* | 2,500 W |
Type | Class-D |
Protection | Short circuit, open circuit, thermal |
Connectors
Input A / B | 2 x combo jack/XLR |
Sensitivity | Line +4 dBu, mic -22 dBu, switchable |
Input impedance | 20 kO unbalanced, 40 kO balanced |
Maximum input level | +21 dBu |
Output A / B | 2 x XLR Linked to input |
Mix output | XLR, balanced |
Output impedance | 100 O unbalanced, 200 O balanced |
Ultranet input/link | 2 x RJ45 |
Mains Supply | Neutrik powerCON input 20A and link 15A |
Controls
DSP | Rotary push-encoder |
Mixer section | 2 x gain controls (channels A and B) |
User DSP Functions
Factory EQ presets | Positioning, Sound mode |
Display | LCD 128 x 32, blue backlit |
Delay | 0 - 300 ms |
Equalisation | High and low shelving EQ |
Limiter | Zero attack input limiter |
Presets | 20 total presets, 19 user-definablenable |
Crossover | High Pass L-R 24 dB/oct |
Protection | Lock-out function for all settings |
Ultranet Digital Network
System | |
Cabling |
Power Supply
Power consumption | 150 W @ 1/8 max power |
Voltage (fuses) |
Enclosure
Dimensions HWD | 526 x 324 x 316 mm(20.7 x 12.7 x 12.4") |
Net weight | 17.2 kg (38 lbs) |
Construction | Injection-moulded polypropylene enclosure |
Finish | Black painted |
Grille | Powder coated perforated steel |
Flying hardware | M10 x 3 points |
Accessories
IQ10-WB Steel wall bracket |
